sbiddle
30853 posts

Uber Geek
+1 received by user: 9996

Retired Mod
Trusted
Biddle Corp
Lifetime subscriber

  #2660908 22-Feb-2021 07:23
Send private message

Nate001:



I'd get a RJ45 keystone and use a $5 punch tool from jaycar - https://www.jaycar.co.nz/punch-down-tool-for-nz-wall-sockets/p/YT7134



I've used this one before when I was without a proper tool.





I'd seriously rate the chance of anybody on here successfully terminating stranded cable to a keystone jack with one of those plastic tools AND it passing a test (so it's actually going to work correctly) at probably 20%. It is simply not a good idea. With a metal punchdown tool (Jaycar sell them as well for $10) I'd increase that to 75% but would only ever do it as a temporary solution until I had the proper tools / hardware.



The fundamental issue is that stranded and solid cable are very different and the teeth engage cable in different ways, which you can see when you compare RJ45 stranded connectors to RJ45 solid connectors.








nztim
4022 posts

Uber Geek
+1 received by user: 2722

ID Verified
Trusted
TEAMnetwork
Subscriber

  #2660910 22-Feb-2021 07:30
Send private message

sbiddle:

Nate001:


I'd get a RJ45 keystone and use a $5 punch tool from jaycar - https://www.jaycar.co.nz/punch-down-tool-for-nz-wall-sockets/p/YT7134


I've used this one before when I was without a proper tool.



I'd seriously rate the chance of anybody on here successfully terminating stranded cable to a keystone jack with one of those plastic tools AND it passing a test (so it's actually going to work correctly) at probably 20%. It is simply not a good idea. With a metal punchdown tool (Jaycar sell them as well for $10) I'd increase that to 75% but would only ever do it as a temporary solution until I had the proper tools / hardware.


The fundamental issue is that stranded and solid cable are very different and the teeth engage cable in different ways, which you can see when you compare RJ45 stranded connectors to RJ45 solid connectors.






PDL/Keystone jacks don't bite into stranded cable at all




Any views expressed on these forums are my own and don't necessarily reflect those of my employer.


Ghostextechnica

41 posts

Geek
+1 received by user: 2


  #2663114 26-Feb-2021 13:40
Send private message

Just to wrap this up - all worked out perfectly. Thanks all for your help!










nztim
4022 posts

Uber Geek
+1 received by user: 2722

ID Verified
Trusted
TEAMnetwork
Subscriber

  #2663210 26-Feb-2021 17:23
Send private message





what did you end up doing in the end?









Any views expressed on these forums are my own and don't necessarily reflect those of my employer.
