I am looking to get a 20ft shipping container to use a workshop







Doing some research and the problem being a tin-can is that they can get very hot inside in summer and then in winter it can be prone to condensation inside







To prevent condensation people insulate the walls of the shipping containers on the inside with  pink batts then braced and covered with gib board







Also ventilation is key , like installing a "whirly bird" on the roof of the shipping container







I was wondering what if the insulation was on the outside of the shipping container using polystyrene insulation again the walls and roofs then braced and covered with plywood ,would this help with condensation and cooling ?







or







I was wondering what if the insulation was on the outside of the shipping container and there was a "air gap" between the polystyrene insulation and the shipping container







or







having the insulation on the outside defeats the purpose and won't work







Any idea?







(the reason for insulation on the outside is not loose the space on the interior walls to insulation)


Create new topic
nickb800
2735 posts

Uber Geek
+1 received by user: 829

Trusted

  #2147067 18-Dec-2018 12:56
Send private message

Simplest approach would be to insulate the inside - could do 50mm polystyrene glued to the container walls/ceiling with a thin lining glued to the polystyrene for durability e.g. 5mm plywood or MDF. You would only loose 110mm (2x55mm) off the width and length of the container.



Insulating and cladding the outside would be a lot of work as you need complicated detailing around the door to keep heat out of the container and water out of your cavity. That said, a common problem with containers is rusting roof due to water sitting on the flat roof, so if you framed a pitched roof with eaves as part of this, then this would extend the lifespan of your container.








mudguard
2355 posts

Uber Geek
+1 received by user: 1266


  #2147069 18-Dec-2018 12:57
Send private message

A friend of mine in Alexandra did this. Has insulation, glazed sliding door and heatpumps. He used for about year whilst his office and workshop were being built.
Might be worth giving Dougal a call.
https://www.shockcraft.co.nz

DonH
232 posts

Master Geek
+1 received by user: 158

Lifetime subscriber

  #2147079 18-Dec-2018 13:19
Send private message

Get an old reefer? (Refrigerated container) Pre-insulated...



Or get a regular container and have the inside sprayfoam insulated. If you use batts you need to put a moisture barrier between the batts and the gib-board.



You're better off insulating and lining the inside, if you do the outside you have to go to some trouble to make sure it is weathertight to prevent water ingress behind the cladding.




gehenna
8676 posts

Uber Geek
+1 received by user: 3903

Moderator
Trusted
Lifetime subscriber

  #2147082 18-Dec-2018 13:22
Send private message

"Workshop"




SirHumphreyAppleby
2962 posts

Uber Geek
+1 received by user: 1888


  #2147083 18-Dec-2018 13:25
Send private message

DonH:



Get an old reefer? (Refrigerated container) Pre-insulated...





Used reefers aren't a good idea as they may have moisture trapped in the walls or be contaminated by their previous content.


xcon

147 posts

Master Geek
+1 received by user: 24

ID Verified

  #2147146 18-Dec-2018 14:52
Send private message

Thanks guys :)



I seen a youtube video were sprayfoam insulated was used to insulate the inside



I didn't even know this "If you use batts you need to put a moisture barrier between the batts and the gib-board" hehe tongue-out







Interior insulation seems to be the way to go and common on my research







Thanks Nickb800 , I think polystyrene and plywood on the interior walls maybe the option to go with



Thanks for the heads-up on the flat-roof that is common rust area :)















Shop now on Samsung phones, tablets, TVs and more (affiliate link).
DonH
232 posts

Master Geek
+1 received by user: 158

Lifetime subscriber

  #2147203 18-Dec-2018 15:44
Send private message

I hadn't thought of polystyrene and plywood. Easier than studs and gib board, also easier to DIY. smile



You can get foam sheets with aluminium foil on one side. Seal all the joints between the sheets with tape, to prevent moisture getting through and condensing on the steel in winter. It's not usually done in NZ houses, but in countries where it gets much colder in winter a vapour barrier on the "warm" side of the insulation is often required by by building regulations. Spray foam is popular because it provides both insulation and a barrier.


MikeAqua
8203 posts

Uber Geek
+1 received by user: 3957


  #2147215 18-Dec-2018 16:09
Send private message

+1 for get a reefer - pre-insulated and often stainless lined too.



They also have an end compartment that is open on one side - where is where the refrigeration plant was.  This is great spot for a compressor, generator, LPG bottles or some other plant you want outside the main work space.  They also have air ducting from the plant compartment into the floor. If you rig up an extractor fan in the roof, air will be sucked in through the floor, up and out of the roof.





Mike


mudguard
2355 posts

Uber Geek
+1 received by user: 1266


  #2147365 18-Dec-2018 20:50
Send private message

Actually that must be what my friend in Alexandra had, a reefer. As the heatpump unit was in the end where I guess the original one would've have been. It was used all through their winters and summers.


Goosey
3053 posts

Uber Geek
+1 received by user: 894

Subscriber

  #2147435 18-Dec-2018 21:49
Send private message

These links should give you some really good ideas....







https://www.royalwolf.co.nz/container-modifications



http://containersmore.co.nz/customised-container-new.html



https://www.boxman.co.nz/shipping-containers.aspx


tdgeek
30088 posts

Uber Geek
+1 received by user: 9525

Trusted
Lifetime subscriber

  #2147542 19-Dec-2018 07:59
Send private message

There was a container home, 40 ft on Stuff just the other day but I can't find it. They insulated the outside, to avoid reducing the interior space. Even though insulation insulates, if the metal was baking in sun or freezing in winter, thats bound to have an effect, but insulating the outside and covering that with cladding means the metal is not going to have any opportunity to use its properties of conducting heat and cold






Support Geekzone with one-off or recurring donations Donate via PressPatron.
sudo
410 posts

Ultimate Geek
+1 received by user: 117


  #2148297 20-Dec-2018 11:46
Send private message

I saw a container with a hinged roof with solar panels. That would reduce the sunlight/rain on the roof and give you a self-powering project :-D



And why not put a small vent on each end of the container. Have a fan, on the shady side, to push cooler air in summer and pull out air in winter.
