PXC / Ozito 2x4Ah battery + fast charger $109

To post in this sub-forum you must have made 30 posts or have Trust status or have completed our ID Verification

Forums › Bargains and Deals › PXC / Ozito 2x4Ah battery + fast charger $109

1 | 2 | 3 | 4

2942 posts

Uber Geek
+1 received by user: 1863

#2961720 31-Aug-2022 21:23

Jaxson: Any recommendations on a nice drill to pair with these.
After just a solid standard drill.

The basic Ozito drill they sell in the cheap kit is a bit rubbish. Gets the job done, but it feels like it should spin much faster. Okay for wood/aluminium, not so much if you want to drill into brick or steel.

I'd probably go for the brushless hammer drill if I had more of a use for the drill. I mostly use the driver (I have two of the cheap ones), and they're fine.

pih

667 posts

Ultimate Geek
+1 received by user: 359

Lifetime subscriber

#2962853 3-Sep-2022 19:46

Regarding the coil whine, I returned my unit to Bunnings today and it turned out the Ozito rep was in store. Asked him if he'd heard it before and he said no. We plugged it in and sure enough there it was. In the store you had to put your ear close to it to hear it, so we unboxed another one and... Same noise 😳. The second one was a little quieter, so I ended up swapping them anyway, but that was disappointing.

neb

11294 posts

Uber Geek
+1 received by user: 10018

Trusted

Lifetime subscriber

#2962861 3-Sep-2022 20:11

pih: Regarding the coil whine, I returned my unit to Bunnings today and it turned out the Ozito rep was in store. Asked him if he'd heard it before and he said no. We plugged it in and sure enough there it was. In the store you had to put your ear close to it to hear it, so we unboxed another one and... Same noise 😳. The second one was a little quieter, so I ended up swapping them anyway, but that was disappointing.

It means they've saved a few cents by not sealing a ferrite somewhere. If it's an open toroidal inductor (quite likely) you can try encasing it in hot glue to try and damp the whine down, in less budget-critical consumer electronics they're usually potted to deal with this.

Can you post a photo of the insides for the peanut gallery to comment on?

Jaxson

8172 posts

Uber Geek
+1 received by user: 1332

Trusted

#2963195 4-Sep-2022 22:01

SirHumphreyAppleby:
Jaxson: Any recommendations on a nice drill to pair with these.
After just a solid standard drill.

The basic Ozito drill they sell in the cheap kit is a bit rubbish. Gets the job done, but it feels like it should spin much faster. Okay for wood/aluminium, not so much if you want to drill into brick or steel.

I'd probably go for the brushless hammer drill if I had more of a use for the drill. I mostly use the driver (I have two of the cheap ones), and they're fine.

Went in for the Ozito and came out with the Ryobi ONE+ deal in the end.
Brushless Drill and Driver and two larger alacrity batteries for $249.
Not a dual charger but looks pretty nice and has a decent manufacturer warranty.

pih

667 posts

Ultimate Geek
+1 received by user: 359

Lifetime subscriber

#2968332 14-Sep-2022 22:40

neb:
It means they've saved a few cents by not sealing a ferrite somewhere. If it's an open toroidal inductor (quite likely) you can try encasing it in hot glue to try and damp the whine down, in less budget-critical consumer electronics they're usually potted to deal with this.

Can you post a photo of the insides for the peanut gallery to comment on?

Sorry for the delay, finally got the thing pulled apart tonight to investigate. It's interesting:

There's a step UP transformer on the mains input on the right side which bumps the input up to ~337VDC. Weird. Then feeding off that is two switched mode step down supplies, one for each battery.

It's the two yellow and black transformers making all the racket. As suggested (thanks) I entombed them in hot glue, and now the squeal is barely perceptible! I just hope those transformers don't get too hot...

neb

11294 posts

Uber Geek
+1 received by user: 10018

Trusted

Lifetime subscriber

#2968334 14-Sep-2022 23:33

pih: There's a step UP transformer on the mains input on the right side which bumps the input up to ~337VDC. Weird. Then feeding off that is two switched mode step down supplies, one for each battery.

It's the two yellow and black transformers making all the racket. As suggested (thanks) I entombed them in hot glue, and now the squeal is barely perceptible! I just hope those transformers don't get too hot...

PFC circuitry perhaps? Looks like an LC hash filter at the input, but then it looks like the bridge rectifier is after the transformer not before it which is where you'd expect it for PFC circuitry... and I can't see any switchmode controller IC by the chopper transistors, are the second set of heatsinked TO220-ish devices linear regulators and they're relying on those for regulation? Definitely a weird design, must tear my (standard) charger open again and see what's in there, I remember missing any obvious SMPS controller in that as well.

In terms of hot glue, you could always run it for awhile, yank the case open, and point an IR thermometer at it to see what maximum temp it reaches. Worst case the glue will go soft and then re-harden as it cools. Assuming it won't get hot enough that it's risking transformer failure but just affecting the hot glue you could try epoxy putty, e.g. Knead-It.

Mighty Ape

Shop now at Mighty Ape (affiliate link).

neb

11294 posts

Uber Geek
+1 received by user: 10018

Trusted

Lifetime subscriber

#2968858 15-Sep-2022 23:38

I've pulled my standard charger apart and the circuitry is identical, there's just a single SMPS instead of the dual ones. The chopper is a CS7N65F power MOSFET and the second TO220 is an HBR10200 Shottky barrier rectifier. There's definitely a feedback circuit to the chopper via the EL817 optocouplers, but everything else on there is passives, a few capacitors and a resistor. Unless they've hiding a TL494 or something on the underside there's no PWM controller running the chopper.

Ah, and mine doesn't have the LC filter on the input, but it's also a 2017 design. Maybe they got complaints...

Zeon

3926 posts

Uber Geek
+1 received by user: 759

Trusted

#3181904 14-Jan-2024 23:36

Hey all, not sure if anyone else saw but today at Bunnings Glenfield 2x 4Ah batteries + twin fast charger (bit different than the original item from the thread) was $69 inc. GST. I triple confirmed with the lady running the tools section and even showed her the $179 for 2x 4Ah + single fast charger. She scanned and confirmed all correct.

In any case I bought 3x sets. Little bit sad as I bought the $179 set 1 week ago :(

Speedtest 2019-10-14

Bung

6734 posts

Uber Geek
+1 received by user: 2927

Subscriber

#3181924 15-Jan-2024 08:36

Zeon: In any case I bought 3x sets. Little bit sad as I bought the $179 set 1 week ago :(

In their mind the reduction in price wouldn't justify any refund as the product is a different combination of battery and charger. I think the $69 price was available briefly at end of last year. I was expecting the 2 battery/2 charger pack around $110 near Xmas. The normal price for 1 4ah battery is $99. Are they trying to provoke panic buying?

openmedia

3449 posts

Uber Geek
+1 received by user: 878

Trusted

#3182172 15-Jan-2024 12:17

Zeon:

Hey all, not sure if anyone else saw but today at Bunnings Glenfield 2x 4Ah batteries + twin fast charger (bit different than the original item from the thread) was $69 inc. GST. I triple confirmed with the lady running the tools section and even showed her the $179 for 2x 4Ah + single fast charger. She scanned and confirmed all correct.

In any case I bought 3x sets. Little bit sad as I bought the $179 set 1 week ago :(

Just picked up a set myself. Excellent deal.

Generally known online as OpenMedia, now working for Red Hat APAC as a Technology Evangelist and Portfolio Architect. Still playing with MythTV and digital media on the side.

russelo

332 posts

Ultimate Geek
+1 received by user: 43

#3182209 15-Jan-2024 13:37

Not showing on Bunnings website. What's the product number written on Bunnings price sticker? I want to check if its available in my local Bunnings store.

I already have 10 batteries but so tempted to buy at this price.

Quic Broadband

Move to New Zealand's best fibre broadband service (affiliate link). Free setup code: R587125ERQ6VE. Note that to use Quic Broadband you must be comfortable with configuring your own router.

Zeon

3926 posts

Uber Geek
+1 received by user: 759

Trusted

#3182212 15-Jan-2024 13:43

Speedtest 2019-10-14

clicknz

477 posts

Ultimate Geek
+1 received by user: 94

Trusted

#3182326 15-Jan-2024 18:20

Hi - thanks for the heads-up on this... I checked my local Bunnings in Wellington (Lyall Bay), but unfortunately they didn't have this deal going.

I was interested in getting one of the USB adapters to slide onto the Ozito batteries - the local ones have 2 USB A out connectors but I found one on Aliexpress that had one USB-c power delivery plus a USB A so I ordered that and it arrived very quickly (listed for Einhell batteries that I believe are the same as Ozito - it works fine on my Ozitos).

I just searched again and there's another variation (with light) that I didn't see a few weeks ago - Ali Link

Cheers,

Mike

johno1234

3357 posts

Uber Geek
+1 received by user: 2843

#3182392 15-Jan-2024 19:32

Can you invoke Pricematch against themselves?

Bung

6734 posts

Uber Geek
+1 received by user: 2927

Subscriber

#3182398 15-Jan-2024 19:44

johno1234:
Can you invoke Pricematch against themselves?

It's not that the other branches have that item at a higher price, they don't have it at all. They might have a twin pack with a different charger or they're just out of stock of Ozito batteries. Hard to tell if Bunnings care, they can always steer new customers to another exclusive brand Ryobi.
