Win7 ATI Catalyst driver issue with 1080i (TV3)

Forums › Home Theatre (including HTPC and EPG Collector) › Win7 ATI Catalyst driver issue with 1080i (TV3)

techo

46 posts

Geek
+1 received by user: 1

#38175 24-Jul-2009 18:39

I'm seeing an issue on Win7 Media Center with the ATI Catalyst drivers 9.7 & 9.8. 1080i content (TV3) has 1sec bursts of pixelation/corruption occuring regularily every minute or so. This occurs on LiveTV and Recorded-TV. This is not a tuner issue.

Edit: Actually what I think I'm seeing is corruption, not pixelation, because a few times I've seen a repeated frame from a few seconds ago mixed with the current frame.

Anyone else seeing this issue?

Win7 64bit RC, ATI 4670, Catalyst 9.8

Works for Vodafone NZ. Any opinions expressed on Geekzone are my own, and not of my employer.

sbiddle

30853 posts

Uber Geek
+1 received by user: 9996

Retired Mod

Trusted

Biddle Corp

Lifetime subscriber

#238809 25-Jul-2009 01:40

What is your signal strength like?

Picture breakup is typically a signal related problem.

BlueToothKiwi

282 posts

Ultimate Geek
+1 received by user: 3

Trusted

#238812 25-Jul-2009 06:21

Yeah - I agree with Biddle. The best way to be sure - replay the recorded content back using a different computer - and if you still get the issue you know it is not a display issue.

What tuner are you using - if you are using Hauppauge - get the new Win 7 driver from http://www.hauppauge.co.uk/site/support/support_support.htm

The next step is to see what the signal strength is. If it shows less than 90% - then that will be the most likely cause. I am only saying that as I have not had any problems since I got the new Catalyst 9.7 drivers.

Tim M, Auckland
Blog: http://paddler.co.nz

techo

46 posts

Geek
+1 received by user: 1

#238833 25-Jul-2009 09:33

Thanks guys for the feedback. It appears I'm the only one with this issue, so I'll do some more investigation.

To confirm this was not a tuner issue, I recorded TV3 using my Vista PC running GBPVR, and confirmed it played-back ok on that PC, then copied the file to the Win7 PC and played-back on 7MC which displays the pixelation issue on this known good recording. This issue is also seen on 7MC LiveTV using either of my tuners (Hauppauge HVR2200, DigitalNow "DNTV Dual Hybrid PCIe S2") to which both tuners have 100% signal quality.

So no-one else is seeing this issue?

Works for Vodafone NZ. Any opinions expressed on Geekzone are my own, and not of my employer.

Ragnor

8279 posts

Uber Geek
+1 received by user: 585

Trusted

#238900 25-Jul-2009 15:28

Can you post a small sample of one the 1080i files with the problem, I've give it a test on my 4770 if you like.

techo

46 posts

Geek
+1 received by user: 1

#238911 25-Jul-2009 15:56

Thanks Ragnor for the offer, but I've been doing more testing and now 100% sure it is not caused by the recording itself.

When watching TV3 LiveTV and I notice a pixelation burst, I timeshift back and re-play that segment again, which replays OK. The pixelation never re-occurs at exactly the same point, but is still occuring relatively regularily at 1 minute intervals (offset relative to the start point of the replay).

Taking this a step further, I have installed Win7 on my HTPC which has completely different hardware to my existing Win7 PC (except still using the ATI 4670 video card), and I experience exactly the same TV3 pixelation issue on that PC as well.

I have also tried a ATI 3650 card, but same result.

Edit: Actually what I think I'm seeing is corruption, not pixelation, because a few times I've seen a repeated frame from a few seconds ago mixed with the current frame.

Works for Vodafone NZ. Any opinions expressed on Geekzone are my own, and not of my employer.

jeavons

19 posts

Geek

#245019 10-Aug-2009 23:23

I got same problem as techo, I rolled back to 9.3, the problem solved. I think it is the driver's problem.

Geekzone support

Support Geekzone with one-off or recurring donations Donate via PressPatron.

jeavons

19 posts

Geek

#245021 10-Aug-2009 23:38

I used Win7DSfilter to change the decoder to MPC-HC's video decoder. It was getting better, and I think the problem is solved.

Download from http://www.codecguide.com/windows7_preferred_filter_tweaker.htm

you also can download the MPC-HC decoder from

http://www.xvidvideo.ru/component/option,com_docman/task,cat_view/Itemid,11/gid,19/orderby,dmdate_published/

Acrux

56 posts

Master Geek
+1 received by user: 3

#245265 11-Aug-2009 16:35

I have had the same issue with an ATI card on v9.7 in Win7 (32RC) I initially had this card installed with v9.6 which didn't support the playback of SD content while TV1, 2, 3 were fine. I switched to a NVIDIA card and all was almost better, except that after about five minutes into watching anything on live TV the video started dropping frames until it ws unwatchable. However a simple pause then play or channel change would bring it right. After hearing that v9.7 was out i swapped back to the ATI card and now have the same picture pixelisation/ breakup issue you describe.

PC               Core i7 920, Asus P6T motherboard, 6 Gb RAM
Capture      HVR-2200
Video          Gigabyte GTX260
Software    Win 7 64bit, Windows Media Center, Big Screen EPG

jeavons

19 posts

Geek

#245327 11-Aug-2009 19:11

I test the live TV for the whole day, the problem actually still not fixed by my way. I think it is driver's problem. I got this problem for MediaPortal on v9.7 as well. After I changed back to v9.4, everything works fine for MediaPortal.

techo

46 posts

Geek
+1 received by user: 1

#249536 21-Aug-2009 20:12

FYI - this issue is also reported on TGB forum on BBC-HD broadcasts.
http://thegreenbutton.com/forums/p/73544/365756.aspx#365756

And now also reported on ATI forum
http://forums.amd.com/game/messageview.cfm?catid=260&threadid=117619&forumid=11

Works for Vodafone NZ. Any opinions expressed on Geekzone are my own, and not of my employer.

BlueToothKiwi

282 posts

Ultimate Geek
+1 received by user: 3

Trusted

#249561 21-Aug-2009 22:23

Weird - I just replied in the ATI thread..

Tim M, Auckland
Blog: http://paddler.co.nz

Geekzone support

Support Geekzone with one-off or recurring donations Donate via PressPatron.

dale77

298 posts

Ultimate Geek

#249689 22-Aug-2009 16:13

I also replied to the ATI thread, I have seen the problem once only.

HTPC: Antec Fusion 430, Intel i3, Gigabyte 1050, Corsair 4x1Gb, Hauppauge WinTv, Logitech z-5500, Logitech Harmony 525, Yamaha Rx-v6a, Samsung KS8000 4k, Windows 10, Mediaportal 1.30, BLU-RAY: Panasonic UB820
