Broadband installed on Friday afternoon.
I came in on Saturday and tested: no dial tone/adsl.
tech comes back out monday afternoon and now testing tuesday morning I finally have services.
My broadband performance is unusable.

Sync rates from modem:

real world national speed:

real world international speed:

real world international speed:

wow - what a shocker! totally unusable.
I used to sync at 16-18Mbps with Orcon a year ago at the same location and consistently get real world international download speeds between 12 and 16Mbps down.
The soft phone was a bit flakey, but hardly used it.

Getting a call back tomorrow from the throughput team, so I hope they can work some magic otherwise I will be forced to quit and try Orcon.
I am 1.7km from the Airedale St exchange so I reckon I should be getting around 12Mbps sync minimum.

This is disappointing, I was psyched for the new double data plans!

What annoys me too is that there's a VDSL2 cabinet about 75m away but Chorus said it's not feasible to connect me. That sucks, I would dig the trench or pay for it to be dug!

UFB is too far away, ugh!!

View this topic in a long page with up to 500 replies per page Create new topic
 1 | 2
8033 posts

Uber Geek


  # 610660 17-Apr-2012 16:59
Send private message

What modem are you using?

Post the line stats from the modem admin eg: line attenuation, noise margin etc.

3493 posts

Uber Geek


  # 610667 17-Apr-2012 17:04
Send private message

Possible your area has been cabinetized and you are getting I think its called midpoint injection (check sbiddles post). Otherwise it could be packet loss. Lol you need to start working the problem before straight off saying you will switch providers.....

Speedtest 2019-10-14


162 posts

Master Geek

  # 610677 17-Apr-2012 17:14
Send private message

I couldn't see where the line stats were, I am away from home right now. I turned on remote admin but forgot to write down my IP doh!

You are right, but the level one person started to tell me my speeds were great (!)
Then put me on hold for 5 mins to find the speedtest tool.
No mention of midpoint injection from them, but I guess that is not to be expected.
I will search for the sbiddle post. Hopefully an easy fix!

162 posts

Master Geek

  # 610682 17-Apr-2012 17:17
Send private message

Using the free modem Telecom Technicolour

162 posts

Master Geek

  # 610759 17-Apr-2012 19:38
Send private message

Will the line attenuation and noise margin figures reveal if it's midpoint injection?

What will Telecom do if it is?
Are they up front and admit that midpoint injection exists?

28260 posts

Uber Geek

Biddle Corp
Lifetime subscriber

  # 610766 17-Apr-2012 19:53
Send private message

Midplan injection can't occur with Telecom as your ISP since Telecom only use wholesale services from Chorus, they don't have their own ISAM's.

Assuming you are within a 10Mbps zone according to the Chorus SAT your internal wiring is the first place to look.

162 posts

Master Geek

  # 610812 17-Apr-2012 20:53
Send private message

Link Information

Uptime: 0 days, 0:07:08

DSL Type: ITU-T G.992.5

Bandwidth (Up/Down) [kbps/kbps]: 948 / 6.403

Data Transferred (Sent/Received) [kB/kB]: 218,36 / 326,43

Output Power (Up/Down) [dBm]: 12,3 / 19,0

Line Attenuation (Up/Down) [dB]: 16,3 / 29,0

SN Margin (Up/Down) [dB]: 12,4 / 12,1

System Vendor ID (Local/Remote): TMMB / ----

Chipset Vendor ID (Local/Remote): BDCM / BDCM

Loss of Framing (Local/Remote): 0 / 0

Loss of Signal (Local/Remote): 0 / 0

Loss of Power (Local/Remote): 0 / 0

Loss of Link (Remote): -

Error Seconds (Local/Remote): 0 / 0

FEC Errors (Up/Down): 0 / 11

CRC Errors (Up/Down): 1 / 0

HEC Errors (Up/Down): 2 / 0


162 posts

Master Geek

  # 610820 17-Apr-2012 21:10
Send private message

who can check my internal wiring? the throughput team?

I wasn't asked if I wanted 'wiring and maintenance' when I joined :S

are my line stats showing anything of interest? - don't know how to read them/what to look for.


4202 posts

Uber Geek

  # 610865 17-Apr-2012 22:36
Send private message

Assuming you are within a 10Mbps zone according to the Chorus SAT your internal wiring is the first place to look.

WHAT?! Are you saying old wiring could be to blame? Well I never....

But seriously, coffeebaron is the man to PM

edit: 29db would put your line around 2km-ish I would guess, but you say you are closer. So check for bad joints, old jacks etc.

162 posts

Master Geek

  # 610983 18-Apr-2012 09:01
Send private message

thanks chevrolux, I need to make the coffee baron an Ethiopian Single Origin Syphon filter ;)

8033 posts

Uber Geek


  # 611216 18-Apr-2012 15:33
Send private message

With 29dB downstream line attenuation you would normally expect to be getting around a 16Mbit down line rate like you got on Orcon.

Like the others have mentioned it could be an issue with the phone wiring in your home.

However, you say a you had a tech come out to reconnect the line? It's possible the tech muffed the connection of the line to the house, so it's not connected 100% properly or maybe bad connection at the exchange/cabinet end.

I would have another go at getting Telecom to book a Chorus tech to come out as test/fix it.

If that doesn't work bring in the big gun: Coffeebaron!

5544 posts

Uber Geek

Lifetime subscriber

  # 611465 18-Apr-2012 20:56
Send private message

trakman: thanks chevrolux, I need to make the coffee baron an Ethiopian Single Origin Syphon filter ;)

Yea, that might earn a discount; thought beware, a bad coffee and I double my price :)
Hit my email but if you would like some further help and read my signature below.


Coffee Syphon:

Chorus has spent $1.4 billion on making their xDSL broadband network faster and even more now as they are upgrading their rural Conklins. If your still stuck on ADSL or VDSL, why not spend $195 on a master filter install to make sure you are getting the most out of your connection?
I install - Naked DSL, DSL Master Splitters, VoIP, data cabling and general computer support for home and small business.
Rural Broadband RBI installer for Ultimate Broadband and Full Flavour


Need help in Auckland, Waikato or BoP? Click my email button, or email me direct: [my user name] at geekzonemail dot com

425 posts

Ultimate Geek

  # 612837 21-Apr-2012 15:01
Send private message

Wow, you have purple elements??

3594 posts

Uber Geek


  # 612863 21-Apr-2012 16:51
Send private message

Geez Frazer is that coffee or a Meth lab ..... :)

Yes I am a employee of WxC (My Profile) ... but I do have my own opinions as well Wink


19282 posts

Uber Geek
Inactive user

  # 612883 21-Apr-2012 17:42
Send private message

maverick: Geez Frazer is that coffee or a Meth lab ..... :)
