Ok you electronic troops - need some help please with a small project.

Briefly, Council have told us we have to fence our spa pool and without going into details have said no way and instead have purchased a remote controlled actuator that will slide across the top of the cover.

Now want to install a flexible arm micro switch so that when the cover closes it activates the switch and opens the actuator.

Suggestions please as how to incorporate that into the actuator relay.

The 3rd diagram on the right is for the relay: https://usefulldata.com/2-channel-remote-relay/

Many thanks

Why work on Wednesday and stuff up 2 good long weekends

gregmcc

2173 posts

Uber Geek
+1 received by user: 836

ID Verified

Trusted

Lifetime subscriber

#2326690 29-Sep-2019 12:54

Try this, the only drawback is that you will have to hold down the A or B button until it is fully open or closed, the limit switch should stop it over opening or over closing.

Next problem will be finding some limit switches that will stand up to the hot humid environment of been close to a spa pool.

stuffed

288 posts

Ultimate Geek
+1 received by user: 2

#2326702 29-Sep-2019 13:34

Thanks and think can understand that and will give it a try👌

Why work on Wednesday and stuff up 2 good long weekends

bagheera

544 posts

Ultimate Geek
+1 received by user: 189

#2326732 29-Sep-2019 14:50

might want to read page 17, and check what you planning to do, meet the rules, as you will need to prove it to the Council that you meet the act as they will be checking now that they know about it, if not agree with you, then you will need to go to court to contest it.
