Ultimate Geek

#1839572 5-Aug-2017 17:46

I have one with a Draytek Vigor 130 in Riverlands, Blenheim getting 106 by 49

Exchange BM

DSLAM Port BM_G-DSLAM-03:x-x-x-x

Interleaving Off

Last Port Refresh No Information Available

Last Line Check (Query Chorus) 36 seconds ago

Calling Station xxx-BM_G-DSLAM-x-x-x-x

DSL Type non.shdsl.opermode vdsl2.g9932.profile.17a, line.type.pots

Spectrum Profile Name EUBAV-VDSL2-1

Service Profile Name EUBAV-I-FSFS

Service Template Name VDSL2-I-ddDLM

Modem Vendor ID B5004946544E5480

System Vendor ID B5004946544E0000

System Vendor Model 332E372E382E32000000000000000000

Serial Number 001daa891ae0

Service Stability STABLE

Line Status Up

Upload Download

Actual Bitrate 49.43 Mbps 106.28 Mbps

Capacity Occupation 0.10 Mbps 0.09 Mbps

Parameter Attenuation 13.6 dBm 12.3 dBm

Loop Attenuation 13.9 dBm 12.4 dBm

Noise Attenuation 6.6 dBm 8.7 dBm

Actual PSD -69.5 dBm -58.7 dBm

Power -2.5 dBm 12.0 dBm

sbiddle

30853 posts

Uber Geek

Retired Mod

Trusted

Biddle Corp

Lifetime subscriber

#1839574 5-Aug-2017 17:49

hio77:
sbiddle:

I installed a VDSL2 connection this week that sync and delivers 100Mbps - a speedtest was limited to 94Mbps due to the VDSL2 modem in use only having a 100Mbps port.

Upstream is currently sitting at 38Mbps so it's going to be interesting to observe this in coming weeks to see how much closer to 50Mbps it can get.

I've noticed the upstream at that rate can be heavily modem dependant.

It's with a TP-Link at present but will be moving to a DV130 when I next head back on site.

Jarsky

142 posts

Master Geek

#1839700 6-Aug-2017 07:11

freakngeek:

Jarsky:

I wonder if your rate will stay constant with that FEC count

I noticed that we're on different VDSL firmware as well - that you're running one of the G.Vectoring ones. When I ran the "NZ & AU recommended" G.Vector one it dropped my speed significantly

The Error rate data it seems to have kept from before the resync, does this after a reboot and Factory reset also
Only keeps upload data, DL gets reset every resync
Before the resync last night the FEC count on DL was over 9million, doesn't seem to affect the ddDLM sync any, probably due to the errors being corrected on the fly

Also never had a Saturday morning resync either, always Tuesday and Thursday mornings

I use FW MDM4 at the moment, seems most stable, MDM8 can give higher upload but also more CRC's
STD FW is rubbish as error reporting doesn't work.

Well I just switched to the same m4 firmware again now that my ddDLM has put me on the better profile, and now my attainables have jumped even more.

Damn this Ikanos card

---------------------- ATU-R Info (hw: annex A, f/w: annex A/B/C) -----------
Running Mode : 17A State : SHOWTIME
DS Actual Rate : 70004000 bps US Actual Rate : 29839000 bps
DS Attainable Rate :125270328 bps US Attainable Rate : 32704000 bps
DS Path Mode : Interleave US Path Mode : Interleave
DS Interleave Depth : 218 US Interleave Depth : 645
NE Current Attenuation : 11 dB Cur SNR Margin : 17 dB
DS actual PSD : -2.-7 dB US actual PSD : 14. 5 dB
NE CRC Count : 1 FE CRC Count : 88808
NE ES Count : 1 FE ES Count : 12325
Xdsl Reset Times : 0 Xdsl Link Times : 1
ITU Version[0] : b5004946 ITU Version[1] : 544e0000
VDSL Firmware Version : 05-07-06-0D-01-07 [with Vectoring support]
Power Management Mode : DSL_G997_PMS_L0
Test Mode : DISABLE
-------------------------------- ATU-C Info ---------------------------------
Far Current Attenuation : 13 dB Far SNR Margin : 8 dB
CO ITU Version[0] : b500494b CO ITU Version[1] : 4e530101
DSLAM CHIPSET VENDOR : < IKNS >

Jase2985

13461 posts

Uber Geek

ID Verified

Lifetime subscriber

#1839701 6-Aug-2017 07:23

i know that feeling

AidanP

76 posts

Master Geek

#1839740 6-Aug-2017 08:56

Last night our modem reset and are now on the 17a profile. And believe we are on an ikanos card

freakngeek

356 posts

Ultimate Geek

#1839745 6-Aug-2017 09:20

Jarsky:

DS actual PSD : -2.-7 dB

I wonder if your Downstream connection is limited to this ?
Are you running a lower powered connection ?v(@Hio77) will know more about this
Mine is
DS actual PSD : 9. 0 dB

But 125Mbps attainable is crazy fast with 11db Attenuation

anatokidave

66 posts

Master Geek

ID Verified

#1839768 6-Aug-2017 10:56

@Jarsky:

Nice improvements in ur line stats. I've noted your FW comments.

I understand you are using a DV130.

I'm using the latest version - 3.8.1.2_STD because I understood that G-vectoring was not used in NZ

What do you mean by MDM4 and MDM8?

Equinox IT

Cloud spending continues to surge globally, but most organisations haven’t made the changes necessary to maximise the value and cost-efficiency benefits of their cloud investments. Download the whitepaper From Overspend to Advantage now.

freakngeek

356 posts

Ultimate Geek

#1839770 6-Aug-2017 11:07

anatokidave:

@Jarsky:

Nice improvements in ur line stats. I've noted your FW comments.

I understand you are using a DV130.

I'm using the latest version - 3.8.1.2_STD because I understood that G-vectoring was not used in NZ

What do you mean by MDM4 and MDM8?

Below is a copy of Drayteks FTP for DV130 and FW 3.8.1.2 and options for all Modems
I use Modem 4, Modem 8 has higher upstream connection but for me pushes the connection too far and get more CRC errors

EDIT - Formatted the links

anatokidave

66 posts

Master Geek

ID Verified

#1839806 6-Aug-2017 11:28

@Jarsky:

OK - makes sense now. I was looking at the webpage for DV130 downloads and I couldn't see the ~modem_8 option. However, I see it references that file when I scroll over the ~modem_NBN download.

The DV130 download page now recommends the ~modem_4 FW for NZ and Aus, so things seemed to have changed from when I looked at this a couple of years ago.

(I think when I did my first FW update a year or 2 ago, I relied on some guidelines from Snappernet. This time round I just replaced an earlier version of the STD FW with the latest version)

Jarsky

142 posts

Master Geek

#1840231 6-Aug-2017 20:33

freakngeek:

Jarsky:

DS actual PSD : -2.-7 dB

I wonder if your Downstream connection is limited to this ?
Are you running a lower powered connection ?v(@Hio77) will know more about this
Mine is
DS actual PSD : 9. 0 dB

But 125Mbps attainable is crazy fast with 11db Attenuation

No idea, I don't work in broadband myself so my knowledge is a little limited on it. But heres some details from eSPM

CPE Type: Unknown
DSL Type: non.shdsl.opermode vdsl2.g9932.profile.17a, line.type.pots
Spectrum Profile Name: EUBAV-VDSL2-2
Service Profile Name: EUBAV-FF-FSFS
Service Template Name: VDSL2-I-ddDLM

Parameter Value (U) Value (D)
lqd.parameter.rel.capacity.occupation 90 61
lqd.parameter.attenuation 15.9 11.2
lqd.parameter.loop.attenuation 16.2 11.2
lqd.parameter.noise.margin 3.6 17.5
lqd.parameter.actual.psd -69 -56
lqd.parameter.power -2.4 14.5

hio77

12999 posts

Uber Geek

ID Verified

Trusted

Lizard Networks

#1840440 7-Aug-2017 10:48

freakngeek:

Jarsky:

DS actual PSD : -2.-7 dB

I wonder if your Downstream connection is limited to this ?
Are you running a lower powered connection ?v(@Hio77) will know more about this
Mine is
DS actual PSD : 9. 0 dB

But 125Mbps attainable is crazy fast with 11db Attenuation

power levels is another thing ddDLM can influence, comes into a few conditions however...

#include <std_disclaimer>

Any comments made are personal opinion and do not reflect directly on the position my current or past employers may have.

hio77

12999 posts

Uber Geek

ID Verified

Trusted

Lizard Networks

#1840442 7-Aug-2017 10:49

atomeara:

I have one with a Draytek Vigor 130 in Riverlands, Blenheim getting 106 by 49

@atomeara inhouse? or is that the new interface output chorus teased awhile back?

#include <std_disclaimer>

Any comments made are personal opinion and do not reflect directly on the position my current or past employers may have.

datahawk

251 posts

Ultimate Geek

Lifetime subscriber

#1840850 7-Aug-2017 23:05

Wow!, I had actually given up on ever getting better than 8B and 72/13 out of my rural location and did a random speed test yesterday just to confirm nothing had changed.

Tonight, I decided to check the Draytek 130 just to see if any of the stats had changed and it must have jumped this morning up to a 17A profile.

I am seriously impressed with the current sync and will be a very unhappy camper if DLM comes back and takes away my new toys:

System Uptime:1026:6:23
VDSL Information: VDSL Firmware Version:05-07-06-0D-01-07
Mode:17A State:SHOWTIME TX Block:0 RX Block:0
Corrected Blocks:5254 Uncorrected Blocks:23
UP Speed:36713000 Down Speed:108832000 SNR Margin:5 Loop Att.:12

---------------------- ATU-R Info (hw: annex A, f/w: annex A/B/C) -----------
Running Mode : 17A State : SHOWTIME
DS Actual Rate :108832000 bps           US Actual Rate : 36713000 bps
DS Attainable Rate :106867736 bps      US Attainable Rate : 36714000 bps
DS Path Mode : Interleave                  US Path Mode : Fast
DS Interleave Depth : 389                   US Interleave Depth : 11
NE Current Attenuation : 12 dB            Cur SNR Margin : 5 dB
DS actual PSD : 1. 6 dB                      US actual PSD : 14. 5 dB
NE CRC Count : 23                             FE CRC Count : 5254
NE ES Count : 5                                FE ES Count : 3073
Xdsl Reset Times : 0                          Xdsl Link Times : 10
ITU Version[0] : b5004946 ITU Version[1] : 544e0000
VDSL Firmware Version : 05-07-06-0D-01-07 [with Vectoring support]
Power Management Mode : DSL_G997_PMS_L0
Test Mode : DISABLE
-------------------------------- ATU-C Info ---------------------------------
Far Current Attenuation : 13 dB             Far SNR Margin : 6 dB
CO ITU Version[0] : b5004244 CO ITU Version[1] : 434db1ad
DSLAM CHIPSET VENDOR : < BDCM >

Quick Speed Test = 15ms Ping, 95/33 Mbps

hio77

12999 posts

Uber Geek

ID Verified

Trusted

Lizard Networks

#1840852 7-Aug-2017 23:06

not bad... ddDLM is doing its thing :)

#include <std_disclaimer>

Any comments made are personal opinion and do not reflect directly on the position my current or past employers may have.

AidanP

76 posts

Master Geek

#1840854 7-Aug-2017 23:18

Before I got the 17a profile the day before I had tried shorting out the dsl cable by exposing the 2 wires from an old dsl cable plugging it into the modem and the master splitter then waited for a connection then shorted them which did nothing exept limit our download speed to 10 mbps for a short period but the next day I found out that we were put to the 17a profile, I don't know if this was related to me shorting the cable.
