understanding heat pump label

Forums › Home Workshop DIY › understanding heat pump label

dyllos

22 posts

Geek
+1 received by user: 7

#306248 7-Jul-2023 21:42

Hi, please help me understand the info on the label of the heat pump where I am now staying.. Does it mean that the appliance will draw 96W or less when running? this seems too low...?

thanks

Batman

Mad Scientist
30012 posts

Uber Geek
+1 received by user: 6217

Trusted

Lifetime subscriber

#3101096 7-Jul-2023 21:46

check the label on the compressor outside

Handle9

11922 posts

Uber Geek
+1 received by user: 9674

Trusted

Lifetime subscriber

#3101097 7-Jul-2023 21:46

That's the indoor unit, it's got a small fan in it. The outdoor unit (where the compressor is) will draw most of the power, check that for it's name plate data.

dyllos

22 posts

Geek
+1 received by user: 7

#3101099 7-Jul-2023 21:49

Will do, thanks

timmmay

20857 posts

Uber Geek
+1 received by user: 5349

Trusted

Lifetime subscriber

#3101101 7-Jul-2023 21:58

flxs60gvma - the 60 probably means it's a 6kw heat pump but the indoor unit draws only a little power.

SomeoneSomewhere

1882 posts

Uber Geek
+1 received by user: 1086

Lifetime subscriber

#3101164 8-Jul-2023 09:10

timmmay:

flxs60gvma - the 60 probably means it's a 6kw heat pump but the indoor unit draws only a little power.

6kW cooling capacity. Heating capacity will be a little higher (probably ~7kW). Input power is likely around 2-2.5kW.

Note that this is under rated conditions. Heat pump performance (both capacity and input power, and therefore efficiency) depends quite considerably on indoor and outdoor temperatures, and of course as an inverter model it will reduce power when less than full capacity is required.

timmmay

20857 posts

Uber Geek
+1 received by user: 5349

Trusted

Lifetime subscriber

#3101176 8-Jul-2023 09:34

SomeoneSomewhere:

timmmay:

flxs60gvma - the 60 probably means it's a 6kw heat pump but the indoor unit draws only a little power.

6kW cooling capacity. Heating capacity will be a little higher (probably ~7kW). Input power is likely around 2-2.5kW.

Note that this is under rated conditions. Heat pump performance (both capacity and input power, and therefore efficiency) depends quite considerably on indoor and outdoor temperatures, and of course as an inverter model it will reduce power when less than full capacity is required.

6kw ballpark, as opposed to 80w ballpark.

Apple TV

Stream your favourite shows now on Apple TV (affiliate link).

tweake

2641 posts

Uber Geek
+1 received by user: 1137

#3101217 8-Jul-2023 11:53

SomeoneSomewhere:

6kW cooling capacity. Heating capacity will be a little higher (probably ~7kW). Input power is likely around 2-2.5kW.

Note that this is under rated conditions. Heat pump performance (both capacity and input power, and therefore efficiency) depends quite considerably on indoor and outdoor temperatures, and of course as an inverter model it will reduce power when less than full capacity is required.

thats assuming it has the matching outdoor unit which is not always the case.

the sticker actually mentions it, it depends on the spec of the system.

Gordy7

gordy7
2001 posts

Uber Geek
+1 received by user: 505

ID Verified

Lifetime subscriber

#3101345 8-Jul-2023 15:46

As per your label:

https://www.lawsonair.com.au/daikin-flxs60gvma-6.0kw-floor-ceiling-suspended-air-conditioner

Gordy

My first ever AM radio network connection was with a 1MHz AM crystal(OA91) radio receiver.

gzt

18671 posts

Uber Geek
+1 received by user: 7805

Lifetime subscriber

#3101390 8-Jul-2023 16:01

SomeoneSomewhere: Input power is likely around 2-2.5kW.

Agree. That is maximum and it won't be using that hardly at all. Especially so in a well insulated environment.

tweake

2641 posts

Uber Geek
+1 received by user: 1137

#3101396 8-Jul-2023 16:40

gzt:
SomeoneSomewhere: Input power is likely around 2-2.5kW.

Agree. That is maximum and it won't be using that hardly at all. Especially so in a well insulated environment.

depends on how you use it and what the outdoor conditions are.

variable units (may vary with brand/model) only go into variable mode when close to target temps. as kiwis tend to let houses go cold, the heat pumps run a lot of time at full speed. also with well insulated houses the heat pumps are smaller, lower powered units which take longer to heat a house up. so it ....... depends.
