Is this UFB install job acceptable?

Forums › New Zealand Broadband › Is this UFB install job acceptable?

1 | 2 | 3 | 4 | 5 | 6 | 7 | 8

5346 posts

Uber Geek

Trusted

#1211349 9-Jan-2015 18:20

mckenndk: If you wanted to run your own UFB conduit from the street to your house what would people recommend?

At least if you do it you know it will be done to at least your standard.

Dion

You need to follow this guide (assuming you live in a Chorus UFB area):
https://www.chorus.co.nz/file/2689/urban-service-lead-final.pdf

Whatifthespacekeyhadneverbeeninvented?

DarthKermit

5346 posts

Uber Geek

Trusted

#1211350 9-Jan-2015 18:31

I installed my own conduit to the Chorus standards in that PDF, in late 2014:

It's about 11 metres from our front fence to the front of our house.

Whatifthespacekeyhadneverbeeninvented?

mckenndk

911 posts

Ultimate Geek

#1211355 9-Jan-2015 18:53

That's good to know, where would your source the supplies from?
Won't be looking at doing it until nearer the end of the year I am currently working in Canada but returning home at the end of the year and UFB is high on my list of things I want when I get home.
The place I am right now is the first I have lived in that has VDSL (54 down and 10 up) and I will only want better when I return home.

DarthKermit

5346 posts

Uber Geek

Trusted

#1211358 9-Jan-2015 19:08

I obtained enough 20 mm green telecommunications conduit from second hand building supplies companies to span the 11 metres that I needed. You can probably purchase it from electrical suppliers also.

Whatifthespacekeyhadneverbeeninvented?

DarthKermit

5346 posts

Uber Geek

Trusted

#1440552 4-Dec-2015 14:14

Rather than start a new thread, I thought I would resurrect this one.

Earlier this week, I was excavating a patch of earth for a rental property owner. He wants to extend the driveway concrete pad so that two cars can park on it.

This flat has had UFB installed using the official Chorus green conduit. I dug (with a shovel don't worry) 100 mm down (which is the required minimum depth for driveway concrete) and hit the green conduit on the corner of where the pad is to go. Seems the whole conduit was laid across the front lawn at only this shallow depth.

Is this acceptable practice?

Jase2985

13457 posts

Uber Geek

ID Verified

Lifetime subscriber

#1440566 4-Dec-2015 14:47

https://www.chorus.co.nz/land-development/subdivisions/developing-a-greenfields-subdivision

its actually 450mm according to that page unless it will be under a drive or path where it can be 300mm

DarthKermit

5346 posts

Uber Geek

Trusted

#1440577 4-Dec-2015 14:58

It's not a new subdivision, it's an older flat with a grass front lawn. Because the conduit was laid at such a shallow depth, the new section of concrete will be poured directly on top of the conduit; actually touching it.

Equinox IT

Cloud spending continues to surge globally, but most organisations haven’t made the changes necessary to maximise the value and cost-efficiency benefits of their cloud investments. Download the whitepaper From Overspend to Advantage now.

Jase2985

13457 posts

Uber Geek

ID Verified

Lifetime subscriber

#1440581 4-Dec-2015 15:01

on further looking the link above only seems to be applicable if your are installing a duct.

looking at their step by step here: https://www.chorus.co.nz/installing-fibre/from-the-street-to-your-property/getting-fibre-to-your-property-revised#
it says about 200mm

but still doesnt meet that

mdooher

Hmm, what to write...
1424 posts

Uber Geek

ID Verified

Trusted

Lifetime subscriber

#1440584 4-Dec-2015 15:09

DarthKermit: It's not a new subdivision, it's an older flat with a grass front lawn. Because the conduit was laid at such a shallow depth, the new section of concrete will be poured directly on top of the conduit; actually touching it.

It wont hurt it, If the concrete surrounds it and you are worried about it cracking due to differing expansion rates just wrap it in a couple of layers of insulation tape. Do a sort of rubbish wrinkled job. (pretend you are a Sky installer)

Matthew

DarthKermit

5346 posts

Uber Geek

Trusted

#1440596 4-Dec-2015 15:28

Ok. I do remember saying at the time "Christ, if I had been excavating this lawn with a Bobcat, I'd have gone straight through that conduit without even realising it was there."
